Category: L1e / from 15 y.o.
Length: 1860 mm
Width: 780 mm
Height: 1050 mm
Ground clearance: 270 mm
Wheel base: 1230 mm
Seat height: 810 mm
Weight witout battery: 47 kg
Weight with battery: 55 kg
Rated load: 100 kg
Front suspension travel: 200 mm
Rear suspension travel: 87/210 mm
Motor: DC synchronous permanent magnet
Rated power: 2.05 kW
Max power: 4 kW
Max. limited speed: 45 km/h
Max torque on rear wheel: 250 Nm
Max. range: 100km @20 km/h
Battery: ternary lithium, 60 V /32 Ah /1.9 kWh
Charging time: 3h (100%)
Frame: Aluminium, forged
Tyres: 70 /100 - 19 (F+R)
Brakes: Shimano 4 pistons (F+R)
Category: --
Length: 1860 mm
Width: 780 mm
Height: 1050 mm
Ground clearance: 270 mm
Wheel base: 1230 mm
Seat height: 810 mm
Weight witout battery: 42 kg
Weight with battery: 50 kg
Rated load: 100 kg
Front suspension travel: 200 mm
Rear suspension travel: 87/210 mm
Motor: DC synchronous permanent magnet
Controller: FOC sine wave
Max. limited speed: 45km/h
Max power: 4 kW
Max torque on rear wheel: 250 Nm
Max. range: 100km @20 km/h
Battery: ternary lithium, 60 V /32 Ah /1.9 kWh
Charging time: 3h (100%)
Frame: Aluminium, forged
Tyres: 70 /100 - 19 (F+R)
Brakes: Shimano 4 pistons (F+R)
